August Highlights

Network Basics — Vishal Vaishishth

View the slide deck for this talk here

Evolution of communication systems

Marconi (wireless telegraphy) → One-way radio → Two-way radio (interactive comms) → Digital networks (Ethernet frames, VoIP, etc.)

• Guglielmo Marconi → credited with inventing wireless telegraphy (early radio), which was one-way communication (just sending signals).

• Later, radio tech evolved into two-way communication (walkie-talkies, mobile phones, etc.) where both ends could talk.

• Then we moved into digital communication → carrying not just analog voice but also data.

• Today, even voice calls are chopped into frames/packets (like Ethernet frames in computer networks) when sent over digital/VoIP systems.

OSI Layer

Physical Layer

• The Physical Layer (Layer 1) is responsible for transmitting raw bits over physical media.

• Supports various transmission media:

  • Wires/Cables: Copper (Ethernet CAT5/6/7), Coaxial

  • Optical Fiber: High-speed long-distance communication (up to 58 Gbps with Ethernet over fiber)

  • Radio Waves: Wireless transmission for WiFi, Bluetooth, and cellular networks.

• WiFi is actually Layer 2 (Data Link), but it relies on radio waves as the physical medium.

• Key protocols at Layer 1: IDE, SCSI, Ethernet physical specifications.

• Ethernet uses packet switching rather than circuit switching:

  • Packet switching sends data in discrete frames, making networks more flexible.

  • Circuit switching requires pre-allocated bandwidth for the duration of the communication, which is less efficient for shared networks.

• Layer 1 also defines electrical/optical signal standards, connector types, and transmission speeds

Data Link Layer

• The Data Link Layer (Layer 2) operates on top of the Physical Layer, ensuring devices can communicate reliably over physical media.

• Compatibility is crucial: Protocols are needed so devices from different manufacturers can exchange data.

• Standard Ethernet Frame: Encapsulates data for Layer 2 transmission.

• MAC Address (Media Access Control):

  • Needed to identify devices on the same network.

  • If only two devices are connected on a single cable, addresses aren’t required.

  • When networks scale beyond two devices, MAC addresses allow correct packet delivery.

  • Originally sufficient for small, room-scale networks; now critical for larger, multi-device environments.

• Address Management:

  • Managed at Layer 2 (MAC) and Layer 3 (IP).

  • DHCP on routers assigns IP addresses; devices cannot safely overwrite these without risk.

• Why not just MAC?

  • MAC addresses are not extensible beyond local networks.

  • They are hardware-burned, making replacement difficult.

  • IP addresses are required for network-wide routing and scalability.

• ARP Protocol (Address Resolution Protocol):

  • Maps IP addresses to MAC addresses for local communication.

  • Vulnerable to ARP spoofing and cache poisoning attacks.

• VLANs & Trunking:

  • Segment networks into isolated broadcast domains, enhancing security.

  • Misconfigurations can lead to attacks like VLAN hopping via switch spoofing or double tagging.

  • Tagged VLANs help prevent unauthorized access between segments.

  • ARP spoofing: Attackers send fake ARP replies to associate their MAC with a victim’s IP.

• MOII & MAC Security: MAC spoofing detection is used to enhance Layer 2 security.

Network Layer

• IP Addressing: Enables devices to communicate across different networks using IPv4 or IPv6.

• IPv4 vs IPv6:

  • IPv4 uses 32-bit addresses; IPv6 uses 128-bit, allowing vastly more unique addresses.

  • IP Classes organize IPv4 addresses for network segmentation.

• Documentation IP Blocks (RFC 5737):

  • 192.0.2.0/24 (TEST-NET-1)

  • 198.51.100.0/24 (TEST-NET-2)

  • 203.0.113.0/24 (TEST-NET-3)

  • Reserved for testing; not for production use.

• IPv6 Documentation Prefix: 2001:DB8::/32

  • A special IPv6 block reserved by the IETF (RFC 3849) for documentation, examples, and training.

  • Prevents misuse of real IPv6 addresses in books, blogs, and lab setups.

  • Avoids confusion, accidental traffic leaks, and security risks.

  • Non-routable; any traffic to this range is dropped by routers.

  • Recognized globally as a safe prefix for educational use.

  • Can be subnetted (e.g., 2001:DB8:1::/48) to model real-world configurations.

  • Similar to movie phone numbers starting with 555—looks authentic but never connects.

  • Ensures documentation is professional, consistent, and conflict-free.

  • Example addresses:

    • 2001:DB8:1234::1/64

    • 2001:DB8:abcd:5678::/64

• Private Addresses: 100.64.0.0 - 100.64.128.255 (used by ISPs and Tailscale; avoids collisions).

• DHCP Reservations:

  • Assign fixed IPs without relying on sequential allocation.

• Routing:

  • Direct tapping of Ethernet wires is expensive and impractical; port mirroring on destination devices is preferred.

  • Layer 2 MITM attacks are easier to detect; higher layers offer better protection.

  • Routing protocols: OSPF, BGP, ISIS (mostly for carrier networks).

    • Common Routing Attacks:

      • BGP: Prefix hijack, route leaks, manipulation

      • OSPF: LSA injection, falsification, evil twin, LSU spoofing

      • ISIS: Route spoofing, session hijacking

Transport Layer

• Protocols: TCP, UDP, and ICMP form the core of the Transport Layer.

• NAT (Network Address Translation):

  • Allows multiple devices to share a single public IP.

  • the purpose of NAT is to saves IPv4 addresses and hides internal network structure for security

  • Types: Static NAT, Dynamic NAT, PAT (NAT Overload), Port Address NAT.

• Packet Wrapping

  • TCP traffic can be encapsulated inside UDP packets for tunneling.

  • Reliability is still ensured through TCP sequencing and acknowledgments.

  • Useful when networks restrict or block certain protocols.

  • Enables communication to pass through firewalls, NAT devices, or strict network policies.

  • Common in VPNs and tunneling tools where flexibility and traversal of blocked paths are required.

Security & Protections:

• Maintain ACLs to control access.

• Change default ports to reduce attack surface.

• Use VPNs and tunneling to secure communication.

  • Packet Analysis:

• Tools: tcpdump with drivers like usbpcap and ncap capture interface packets for analysis.

  • Real-World Topologies:

• Designed for carrier gateways and high availability networks.

• For real carrier gateways & high availability infra networks

  • Ref: https://robert.penz.name/779/howto-setup-a-redundant-and-secure-bgp-fulltable-internet-connection-with-mikrotik-routers/
  • TCP Flags:

• PSH (Push): Packet must be processed immediately.

• URG (Urgent): Specifies high-priority packets

  • ICMP, Ping, and Traceroute:

• Used for error reporting, diagnostics, and status messages.

• Traceroute works by incrementing TTL to map the route to the destination.

WiFi Highlights

• WiFi operates at Layer 2 (Data Link), while radio waves act as the physical carrier medium at Layer 1.

• Security Protocols:

  • WPA2 (non-PKS versions) can potentially be decrypted if misconfigured.

  • RADIUS and other authentication protocols manage secure access.

Miscellaneous / Performance Highlights

• Ethernet Performance: CAT cables can support speeds up to 58 Gbps in optimal conditions.

• Data Flow: Every packet leaving a device enters the network for processing.

• Passive Wiretap: Operates at Layer 2 and can intercept traffic without detection, highlighting the importance of network security

The session ended at the Transport Layer, while the higher layers :- Session, Presentation, and Application were left out. These will be covered in Application Security (AppSec), keeping the focus here on core networking basics first

---

Hardware Arsenal

View the slide deck for this talk here

What is it?

• Hardware/Hacking Arsenal → Tools designed for specific protocols with compromise as the ultimate goal.

• Focus → How much can you breach without breaking cover?

• Uses → Military operations, physical red teaming, and fun research.

P4wnP1 A.L.O.A

• Turns Raspberry Pi Zero W / Pico W into a powerful, low-cost pentesting tool.

  (Reference:-https://www.raspberrypi.com/documentation/)

• Acts like a WiFi Rubber Ducky with HIDScript (DuckyScript-style payloads).

  (Refrence:-https://github.com/majdsassi/Pico-WIFI-Duck)

• Can emulate keyboard, mouse, storage, and more for red teaming & research.

Pwnagotchi

• AI-powered WiFi sniffer (A2C + bettercap) that learns from its environment.

• Captures WPA handshakes & PMKIDs (saved as PCAPs for hashcat)

• PMKID (Pairwise Master Key Identifier) is a unique value in WPA/WPA2 Wi-Fi that speeds up roaming but can also be captured for offline password cracking.

• A digital pet for hackers running on Raspberry Pi Zero W/2W, 3, and 4.

  (Refrence:-https://github.com/JakerHuber/Jakes-Pwnagotchi-Tutorial.git)

Flipper Zero

• Portable multi-tool for pentesters & hackers in a toy-like body.

• Hacks radio, access control, hardware, and more.

• Open-source & customisable with modular extensions.

PortaPack (for HackRF)

• Add-on with touchscreen, controls, SD slot, clock, and case.

• Turns HackRF into a portable spectrum explorer (few MHz – 6 GHz).

  (Refrence:-https://github.com/pavsa/hackrf-spectrum-analyzer.git)

• Runs on USB battery + proper antenna. (Can be misused for illegal activity)

Keyless Entry & Rolling Code

• Used in cars & garage doors for remote lock/unlock.

• Rolling Code: generates single-use passcodes so codes don’t repeat.

• Exploit angle → If the signal doesn’t reach the car, the sequence can be intercepted & abused.

USB-C

• 24-pin reversible connector, replacing older USB types.

• EU mandate:

  • Phones, tablets, cameras & headphones → by Dec 28, 2024

  • Laptops → by Apr 28, 2026

• Goal: One universal charger/cable.

BAD USB-C (Overview)

• ESP32 Pico-based USB-C implant for executing keystrokes.

• Can run scripts, payloads, admin/root commands.

• With WiFi onboard, it can even bypass air-gapped systems (requires physical access).

Example:

BAD USB-C is an ESP32 Pico-based implant disguised as a USB-C device. It behaves like a normal USB peripheral, but in reality, it executes automated keystrokes and connects over WiFi.

How It Works

1. Physical Access → Connect the BAD USB-C to the target computer.

2. Remote Control → Connect to the device from your laptop, VM, or even a smartphone hotspot.

3. Payload Execution → BAD USB-C injects keystrokes on the victim’s machine as if typed by a user.

Example Attack Scenario

• Prepare a payload script (PowerShell or Batch).

• BAD USB-C executes automatically once plugged in:

  • Opens Command Prompt or PowerShell.

  • Elevates to Administrator (via keystroke sequence).

  • Executes your script, e.g.:

    • Copies documents, credentials, or browser data.

    • Compresses them into a hidden archive.

    • Sends them back over WiFi.

Air-Gapped Bypass

An air-gapped system is normally secure because it’s isolated from any network. BAD USB-C, powered by ESP32 Pico with WiFi, can still bypass this protection.

1. Injects payloads via keystrokes (e.g., open CMD/PowerShell).

2. Collects files (docs, creds, logs).

3. Exfiltrates data over WiFi directly to the attacker’s device.

4. Stealth mode: BAD USB-C can connect to a hidden SSID (like a mobile hotspot) for operational security.

Example:-

• Plug BAD USB-C into an air-gapped PC → it runs a script to zip “.docx” files → connects to your hidden mobile hotspot → sends data over WiFi to your laptop.

• The air-gap is silently bypassed.Key point: Unlike normal USB-C, BAD USB-C is both injector and covert channel, making it far more dangerous.

The session showed a clear journey of how communication has evolved and how today’s networks work.

Along with this, the hardware segment showcased practical tools like P4wnP1, Pwnagotchi, Flipper Zero, and PortaPack, giving a glimpse into hardware hacking and security.
